Foot Pedal Valves

Knowledge Base

Learn More >
Foot Pedal Valves are 3-Way or 4-Way valves with 1/4" NPT ports. Two versions are offered; either a low-profile flat pedal or a standard pedal with or without guard.
  Foot Pedals

  • 3-Way & 4-Way
  • 1/4" NPT ports
  • Low-profile flat pedal or a standard pedal
  • Available with or without guard

    •


    To select the right product for your needs, narrow down the search results by choosing the product attributes your application requires.

    Need help? Contact Us >

    Part No.
    Product Description 1-4 of 4
    MMV-F3QM-F 3-Way Foot Pedal Valve with Flat Pedal
    MMV-F4QM 4-Way Foot Pedal Valve with Standard Pedal
    MMV-F4QM-F 4-Way Foot Pedal Valve with Flat Pedal
    MMV-F4QM-G 4-Way Foot Pedal Valve with Plastic Foot Guard
