Miniature air switches utilize a standard miniature single pole, double throw (SPDT) electrical switch, certified UL, CSA, SEMKO and VDE. These models are available in #10-32, M5, manual and female 1/8-27 NPT ports for direct mounting into manifolds.
To select the right product for your needs, narrow down the search results by choosing the product attributes your application requires.
Need help? Contact Us >
| Part No. |
Product Description
1-65
of 65
|
|---|---|
| MAS-1B2-06 | Miniature Air Switch, 3 Amp, 6 psig, QC Terminals, #10-32 Port |
| MAS-1B2-06-P | Miniature Air Switch, 3 Amp, 6 psig, QC Terminals, 1/8” NPT Port |
| MAS-1B2-20 | Miniature Air Switch, 3 Amp, 20 psig, QC Terminals, #10-32 Port |
| MAS-1B2-20-F | Miniature Air Switch, 3 Amp, 20 psig, QC Terminals, 1/8” NPT Port |
| MAS-1B2-20-P | Miniature Air Switch, 3 Amp, 20 psig, QC Terminals, 1/8” NPT Port |
| MAS-1B2-40-F | Miniature Air Switch, 3 Amp, 40 psig, QC Terminals, 1/8” NPT Port |
| MAS-1B2-40-P | Miniature Air Switch, 3 Amp, 40 psig, QC Terminals, 1/8” NPT Port |
| MAS-1B2-65 | Miniature Air Switch, 3 Amp, 65 psig, QC Terminals, #10-32 Port |
| MAS-1B2-65-F | Miniature Air Switch, 3 Amp, 65 psig, QC Terminals, 1/8” NPT Port |
| MAS-1B2-65-P | Miniature Air Switch, 3 Amp, 65 psig, QC Terminals, 1/8” NPT Port |
| MAS-1B2-MN | Miniature Air Switch, 3 Amp, Manual, QC Terminals |
| MAS-1B3-06 | Miniature Air Switch, 3 Amp, 6 psig, Screw Terminals, #10-32 Port |
| MAS-1B3-06-P | Miniature Air Switch, 3 Amp, 6 psig, Screw Terminals, 1/8” NPT Port |
| MAS-1B3-20 | Miniature Air Switch, 3 Amp, 20 psig, Screw Terminals, #10-32 Port |
| MAS-1B3-20-P | Miniature Air Switch, 3 Amp, 20 psig, Screw Terminals, 1/8” NPT Port |
| MAS-1B3-40 | Miniature Air Switch, 3 Amp, 40 psig, Screw Terminals, #10-32 Port |
| MAS-1B3-40-P | Miniature Air Switch, 3 Amp, 40 psig, Screw Terminals, 1/8” NPT Port |
| MAS-1B3-65 | Miniature Air Switch, 3 Amp, 65 psig, Screw Terminals, #10-32 Port |
| MAS-1B3-65-F | Miniature Air Switch, 3 Amp, 65 psig, Screw Terminals, 1/8” NPT Port |
| MAS-1B3-65-P | Miniature Air Switch, 3 Amp, 65 psig, Screw Terminals, 1/8” NPT Port |
| MAS-1B3-MN | Miniature Air Switch, 3 Amp, Manual, Screw Terminals |
| MAS-1C2-06 | Miniature Air Switch, 10 Amp, 6 psig, QC Terminals, #10-32 Port |
| MAS-1C2-06-F | Miniature Air Switch, 10 Amp, 6 psig, QC Terminals, 1/8” NPT Port |
| MAS-1C2-06-P | Miniature Air Switch, 10 Amp, 6 psig, QC Terminals, 1/8” NPT Port |
| MAS-1C2-20 | Miniature Air Switch, 10 Amp, 20 psig, QC Terminals, #10-32 Port |
| MAS-1C2-20-P | Miniature Air Switch, 10 Amp, 20 psig, QC Terminals, 1/8” NPT Port |
| MAS-1C2-40 | Miniature Air Switch, 10 Amp, 40 psig, QC Terminals, #10-32 Port |
| MAS-1C2-40-F | Miniature Air Switch, 10 Amp, 40 psig, QC Terminals, 1/8” NPT Port |
| MAS-1C2-40-P | Miniature Air Switch, 10 Amp, 40 psig, QC Terminals, 1/8” NPT Port |
| MAS-1C2-65 | Miniature Air Switch, 10 Amp, 65 psig, QC Terminals, #10-32 Port |
| MAS-1C2-65-F | Miniature Air Switch, 10 Amp, 65 psig, QC Terminals, 1/8” NPT Port |
| MAS-1C2-65-P | Miniature Air Switch, 10 Amp, 65 psig, QC Terminals, 1/8" NPT Port |
| MAS-1C2-MN | Miniature Air Switch, 10 Amp, Manual, QC Terminals |
| MAS-1C3-06 | Miniature Air Switch, 10 Amp, Screw Terminals, 6 psig, #10-32 Port |
| MAS-1C3-06-P | Miniature Air Switch, 10 Amp, Screw Terminals, 6 psig, 1/8” NPT Port |
| MAS-1C3-20 | Miniature Air Switch, 10 Amp, Screw Terminals, 20 psig, #10-32 Port |
| MAS-1C3-20-F | Miniature Air Switch, 10 Amp, Screw Terminals, 20 psig, 1/8” NPT Port |
| MAS-1C3-20-P | Miniature Air Switch, 10 Amp, Screw Terminals, 20 psig, 1/8” NPT Port |
| MAS-1C3-40 | Miniature Air Switch, 10 Amp, Screw Terminals, 40 psig, #10-32 Port |
| MAS-1C3-40-F | Miniature Air Switch, 10 Amp, Screw Terminals, 40 psig, 1/8” NPT Port |
| MAS-1C3-40-P | Miniature Air Switch, 10 Amp, Screw Terminals, 40 psig, 1/8” NPT Port |
| MAS-1C3-65-F | Miniature Air Switch, 10 Amp, Screw Terminals, 65 psig, 1/8” NPT Port |
| MAS-1C3-65-P | Miniature Air Switch, 10 Amp, Screw Terminals, 65 psig, 1/8” NPT Port |
| MAS-1X0-06 | Miniature Air Switch (less Switch), 6 psig, #10-32 Port |
| MAS-1X0-06-F | Miniature Air Switch (less Switch), 6 psig, 1/8” NPT Port |
| MAS-1X0-06-P | Miniature Air Switch (less Switch), 6 psig, 1/8” NPT Port |
| MAS-1X0-20 | Miniature Air Switch (less Switch), 20 psig, #10-32 Port |
| MAS-1X0-20-F | Miniature Air Switch (less Switch), 20 psig. 1/8” NPT Port |
| MAS-1X0-20-P | Miniature Air Switch (less Switch), 20 psig, 1/8” NPT Port |
| MAS-1X0-40 | Miniature Air Switch (less Switch), 40 psig, #10-32 Port |
| MAS-1X0-40-F | Miniature Air Switch (less Switch), 40 psig, 1/8” NPT Port |
| MAS-1X0-40-P | Miniature Air Switch (less Switch), 40 psig, 1/8” NPT Port |
| MAS-1X0-65 | Miniature Air Switch (less Switch), 65 psig, #10-32 Port |
| MAS-1X0-65-F | Miniature Air Switch (less Switch), 65 psig, 1/8” NPT Port |
| MAS-1C3-MN | Miniature Air Switch, 10 Amp, Screw Terminals, Manual |
| MAS-1X0-65-P | Miniature Air Switch (less Switch), 65 psig, 1/8” NPT Port |
| MAS-1X0-MN | Miniature Air Switch (less Switch), Manual |
| MAS-1B3-20-F | Miniature Air Switch, 3 Amp, 20 psig, Screw Terminals, 1/8” NPT Port |
| MAS-1B2-40 | Miniature Air Switch, 3 Amp, 40 psig, QC Terminals, #10-32 Port |
| MAS-1B3-40-F | Miniature Air Switch, 3 Amp, 40 psig, Screw Terminals, 1/8” NPT Port |
| MAS-1B2-06-F | Miniature Air Switch, 3 Amp, 6 psig, QC Terminals, 1/8” NPT Port |
| MAS-1B3-06-F | Miniature Air Switch, 3 Amp, 6 psig, Screw Terminals, 1/8” NPT Port |
| MAS-1C2-20-F | Miniature Air Switch, 10 Amp, 20 psig, QC Terminals, 1/8” NPT Port |
| MAS-1C3-06-F | Miniature Air Switch, 10 Amp, Screw Terminals, 6 psig, 1/8” NPT Port |
| MAS-1C3-65 | Miniature Air Switch, 10 Amp, Screw Terminals, 65 psig, #10-32 Port |
/
/
